The IV Curve

Duration
  • 05:00
Creator

Interplay Learning

Compatible devices
Created By IconCreated by Interplay Learning
Topics Icon05:00
Compatible Devices IconCompatible DevicesOculus

Topic Description

The course includes the following content:

  • Understand how the current-voltage (IV) curve represents the possible current and voltage values of a PV device: cell, module, or full array.
  • Understand how using a IV curve helps one make decisions about extracting the maximum power from a PV device.
  • Know why a solar device is a “passive” device and why an inverter is uniquely suited to act as its load to achieve maximum power output.
  • Learn how to calculate and use the IV curve to quantify the quality of a solar module using “fill factor.”
  • Know why a solar module or array may have quality issues when the fill factor is too low.
  • Know how the IV curve is affected by changes of the environment and is used for system sizing and design because of: 1) irradiance; 2) temperature of the module; 3) spectral distribution of the light.
  • Explore how “cloud effect” changes the peak irradiance of a solar module.
  • Discover the standard cell temperature used to test and rate solar modules.
  • Learn the relationship between irradiance and ambient temperature and why it must be considered when doing inverter strength sizing.
  • Learn how the IV curve and module output are affected by the nature of the light spectrum.
  • Learn how (AM) air mass affects the power output of a solar module and the industry standard used to test and rate solar modules.
  • Compare the main three testing standards used to test and rate solar modules: STC, PTC, NOCT
  • Learn the newest test standard that is emerging today: NMOT.
  • Discover how IV curves are combined to make arrays in either series or parallel circuits and how this affects current and voltage outputs.
  • Learn how IV curves and Pmax throughout the day determine kWh produced and energy savings for the consumer and how batteries or the grid can compensate for lower energy outputs.
  • Discover why power companies favor west facing arrays.
  • Predict sun’s effect during the summer vs. the winter in East-West orientation.
  • Compare the annual differences between fixed vs single axis vs dual axis arrays and which ones are most cost effective.
  • Understand how some key resources, though not cheap, put you ahead of the competition in testing a solar installation.
  • Solmetric PVA 1500 Volt IV Tester
  • HT I-V500w IV Curve Tester

The topic "The IV Curve" is available as part of this package. Subscribe this package to get access to this topic.
